Structural Steel Detailing Services is an essential process of engineering and demands optimum accuracy. Even a tiny error can result in a loss of valuable time and expense. Structural Steel Detailing is a significant and mandatory process in all kinds of manufacturing and Structural Services construction activities, such as erection of residential and commercial buildings, industries and institutes, as well as shipbuilding. The technique of Steel Detailing is a vital ‘communications link’ that links key professionals like Engineers, Architects, Contractors, Fabricators and others—all of whom are individually as well as collectively liable for the highest levels of accuracy at each stage.

Structural BIM Services involves the development of detailed drawings for Fabricators and Contractors, and consists of plans and estimates, along with other reports and important tasks. The process consists of two main types of drawings—shop drawings and erection drawings.

Structural Shop drawings or detail drawings specify each and every minuscule detail of an individual steel piece or component such as columns, beams, joists, trusses, braces etc. that ought to be produced by a Steel Fabricator. Such drawings comprises of material specifications , module and component sizes and dimensions , surface specs , welding , bolting as well as painting details , and all the other information regarding the fabrication of each component.

• Erection drawings portray dimension plans and stipulate the location of each steel component within the complete structure. These drawings consist of detailed and specific information about the position of each and every component, the requirements for installing them, and all the correlated field work like installing bolts, wedge anchors and welding spots.

• Steel Detailing Services likewise incorporate other important stages such as reinforcing steel detailing, anchor setting plans, steel design, connectivity diagrams, shop bolt summary and BOM (Bill of Materials).

The design, strength and integrity of steel structures are the role of the Structural Engineer, while complying with the major dimensions and building codes are the responsibility of the Architect. The Detailer is in charge of getting the steel detailing drawings authorized by the Structural Engineer and the Architect prior to release for fabrication. Thus Steel Detailing Services plays an eminent role in building construction with accurate structure.
